Tailor-Made Hydraulic Valves: SDS380 Model, Open to Private Label and Custom Orders

控制方式:液控

路数:1 联

额定流量:380 L/min (100.4 US gpm)

最大压力:315 bar (4600 psi)

进油口:SAE 20接头

出油口:SAE 20接头

接口尺寸:SAE 20接头

品牌:BXHS

所属类别:分块式方向阀

产品系列:SDS380系列分块式方向阀

Packagingsize:35*55*22

Grossweight:52.00 kg

库存: 有货

描述

Tailor-Made Hydraulic Valves: SDS380 Model, Open to Private Label and Custom Orders

Tailor-Made Hydraulic Valves: SDS380 Model, Open to Private Label and Custom Orders drawing image

Introducing the SDS380 Series Tailor-Made Hydraulic Valves, your go-to solution for customized hydraulic system needs. These valves offer exceptional performance with a rated flow of 380 L/min and a maximum pressure of 350 bar.

SDS380系列分块式方向阀参数
控制方式	手控, 气控, 电气控, 电液控, 电磁, 液控, 软轴
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
额定流量	380 L/min (100.4 US gpm)
最大压力	315 bar (4600 psi)
进油口	G1-1/2接口, SAE 20接头
出油口	G1-1/2接口
接口尺寸	G1-1/2接口
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
结构类型	分片阀
环境温度范围	-40°C to +80°C (-40°F to +176°F)
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)

Our SDS380 Hydraulic Valves are designed to meet the specific requirements of your hydraulic system. We offer private label and custom order options to ensure your valves seamlessly integrate with your brand and application. The 1-section, sectional valve design provides flexibility and control, making it suitable for a wide range of applications including material handling, construction, agriculture, and industrial vehicles. The valves are compatible with various models such as telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, wheel loaders, tractors and front-end loaders, and harvesters.
