SD8 Series 3 Spool Sectional Directional Hydraulic Valve

控制方式:手控

路数:3 联

额定流量:90 L/min (23.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G1/2接口

出油口:G3/4接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:SD8系列 分块式方向阀

Packagingsize:26*36*16

Grossweight:14.50 kg

库存: 有货

19 次查看了此产品

SD8 Series 3 Spool Sectional Directional Hydraulic Valve

SD8 Series 3 Spool Sectional Directional Hydraulic Valve

SD8 Series 3 Spool Sectional Directional Hydraulic Valve drawing image

The SD8 Series 3 Spool Sectional Directional Hydraulic Valve is a high-performance manual control solution designed for versatile applications in agriculture, construction, and material handling. Featuring a rated flow of 80 L/min and a maximum pressure capacity of 250 bar, this valve provides precise fluid management for machinery like mini-excavators, tractors, and forklifts.

SD8系列 分块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 分片阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联
工作粘度范围 12 - 400 mm²/s (12 cSt to 400 cSt)
额定流量 90 L/min (23.8 US gpm)
最大压力 315 bar (4600 psi)
进油口 G1/2接口, G3/4接口, SAE 10接头
出油口 G1/2接口, G3/4接口, SAE 10接头, 3/4 NPT螺纹
接口尺寸 G1/2接口, SAE 10接头

As a leading manufacturer of premium hydraulic products, we offer the SD8 Series 3 Spool Sectional Directional Hydraulic Valve, engineered for durability and precision. This manual control valve supports a rated flow of 80 L/min (21.2 US gpm) and operates efficiently under pressures up to 250 bar (3600 psi), making it suitable for front-end loaders, skid steers, and wood splitters. Our factory provides comprehensive solutions including OEM, ODM, and customized manufacturing to meet specific technical requirements. We specialize in bulk wholesale and factory-direct supply for global markets. We are actively seeking long-term partnerships with professional distributors, wholesalers, agents, and traders. Whether you need private labeling (OEM) or specific port configurations (G1/2 inlet, G3/4 outlet), our production facility ensures reliable quality and consistent supply for industrial and mobile hydraulic sectors. Enhance your inventory with our versatile SD8 series valves designed for backhoes, telehandlers, and harvesters.
