SD8-Electric unloading valve Manual 4 Spool Sectional Directional Valve

SD8-Electric unloading valve Manual 4 Spool Sectional Directional Valve | Global Supplier

控制方式:手控

路数:4 联

额定流量:90 L/min (23.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G1/2接口

出油口:G3/4接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:SD8系列分块式方向阀

Packagingsize:35*35*17

Grossweight:20.00 kg

库存: 有货

描述

SD8-Electric unloading valve Manual 4 Spool Sectional Directional Valve | Global Supplier

SD8-Electric unloading valve Manual 4 Spool Sectional Directional Valve | Global Supplier drawing image

The SD8-Electric unloading valve Manual 4 Spool Sectional Directional Valve is a high-performance hydraulic valve designed for use in a wide range of industrial applications. With a rated flow of 90 L/min and a maximum pressure of 350 bar, this valve is suitable for use in systems requiring precise control of fluid flow.

SD8系列分块式方向阀参数
控制方式	手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	分片阀
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联
工作粘度范围	12 - 400 mm²/s (12 cSt to 400 cSt)
额定流量	90 L/min (23.8 US gpm)
最大压力	315 bar (4600 psi)
进油口	G1/2接口, G3/4接口, SAE 10接头
出油口	G1/2接口, G3/4接口, SAE 10接头, 3/4 NPT螺纹
接口尺寸	G1/2接口, SAE 10接头

**Product Name:** SD8-Electric unloading valve Manual 4 Spool Sectional Directional Valve

**Control Method:** Manual

**Section:** 4 Section

**Structure Type:** Sectional valve

**Rated Flow:** 90 L/min (23.8 US gpm)

**Max Pressure:** 350 bar (5100 psi)

**Operating Viscosity Range:** 12 - 400 mm²/s (12 cSt to 400 cSt)

**Spool:** 4 Spool

**Series:** SD8 Series

**Application Area:** MATERIAL HANDLING,CONSTRUCTION AND EARTH MOVING,AGRICULTURE,INDUSTRIAL VEHICLES

**Applicable Model:** TELEHANDLER,FORKLIFT,ALL TERRAIN CRANE,STACKER,AERIAL PLATFORM,MOTOR GRADER,MINI-EXCAVATOR,SKID STEER LOADER,COMPACT WHEEL LOADER,TRACTOR AND FRONT-END LOADER
