Modular Solenoid Valve System: DCV58 Valve for Complex Hydraulic Applications

控制方式:电磁

路数:3 联

额定流量:60 L/min (15.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G3/4接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:DCV58系列分块式方向阀

Packagingsize:26*27*11

Grossweight:14.50 kg

库存: 有货

描述

Modular Solenoid Valve System: DCV58 Valve for Complex Hydraulic Applications

Modular Solenoid Valve System: DCV58 Valve for Complex Hydraulic Applications drawing image

The Modular Solenoid Valve System with DCV58 Valve is designed for complex hydraulic applications. With solenoid control, it features a 3-section sectional valve structure, a rated flow of 60 L/min, and a maximum pressure of 350 bar.

DCV58系列分块式方向阀参数
控制方式	电磁, 电磁和手动
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	分片阀
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量	40 L/min (10.5 US gpm)
最大压力	350 bar (5100 psi)
进油口	G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹
出油口	G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹
接口尺寸	G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹

**DCV58 Modular Solenoid Valve System**

**Control Method:** Solenoid
**Section:** 3 Section
**Structure Type:** Sectional valve
**Rated Flow:** 60 L/min (15.8 US gpm)
**Max Pressure:** 350 bar (5100 psi)
**Operating Viscosity Range:** 15 - 75 mm²/s (15 cSt to 75 cSt)
**Ambient Temperature Range:** -40°C to +80°C (-40°F to +176°F)
**Spool:** 3 Spool
**Series:** DCV58 Series
**Application Area:** MATERIAL HANDLING, CONSTRUCTION AND EARTH MOVING, AGRICULTURE, INDUSTRIAL VEHICLES
**Applicable Model:** TELEHANDLER, FORKLIFT, ALL TERRAIN CRANE, STACKER, AERIAL PLATFORM, MOTOR GRADER, TELEHANDLER, MIDI-EXCAVATOR, MINI-EXCAVATOR, SKID STEER LOADER

Modular Solenoid Valve System: DCV58 Valve for Complex Hydraulic Applications
