The DCV58 Solenoid Valve is a high-performance hydraulic valve designed for demanding applications in various industries such as construction, earth moving, agriculture, and industrial vehicles. It features a solenoid control method, a 1-section design, and a sectional valve structure, providing precise control and reliability in harsh operating conditions.
| DCV58系列 分块式方向阀 参数 | |
|---|---|
| 控制方式 | 电磁, 电磁和手动 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 分片阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 350 bar (5100 psi) |
| 进油口 | G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹 |
| 出油口 | G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹 |
| 接口尺寸 | G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹 |
**DCV58 Solenoid Valve for Demanding Applications**
The DCV58 Solenoid Valve is engineered to meet the rigorous requirements of industrial applications. With its robust construction and high-quality components, it offers exceptional performance and durability.
**Key Features:**
* **Control Method:** Solenoid
* **Section:** 1 Section
* **Structure Type:** Sectional valve
* **Rated Flow:** 60 L/min (15.8 US gpm)
* **Max Pressure:** 350 bar (5100 psi)
* **Operating Viscosity Range:** 15 - 75 mm²/s (15 cSt to 75 cSt)
* **Ambient Temperature Range:** -40°C to +80°C (-40°F to +176°F)
* **Spool:** 1 Spool
* **Series:** DCV58 Series
**Applications:**
The DCV58 Solenoid Valve finds applications in a wide range of industrial equipment, including:
* Telehandlers
* Forklifts
* All Terrain Cranes
* Stackers
* Aerial Platforms
* Motor Graders
* Midi-Excavators
* Mini-Excavators
* Skid Steer Loaders
* Compact Wheel Loaders
With its exceptional performance and versatility, the DCV58 Solenoid Valve is an ideal choice for hydraulic systems demanding reliability, precision, and durability.
