The Hydraulic 1 Spool Directional Valve - SDS380 Model offers precise flow control for various industrial applications. With a rated flow of 380 L/min and a maximum pressure of 350 bar, this valve ensures efficient operation in demanding systems.
| SDS380系列 分块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 软轴 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联 |
| 额定流量 | 380 L/min (100.4 US gpm) |
| 最大压力 | 315 bar (4600 psi) |
| 进油口 | G1-1/2接口, SAE 20接头 |
| 出油口 | G1-1/2接口 |
| 接口尺寸 | G1-1/2接口 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联 |
| 结构类型 | 分片阀 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
**Hydraulic 1 Spool Directional Valve - SDS380 Model**
**Control Method:** Hydraulic
**Section:** 1 Section
**Structure Type:** Sectional valve
**Rated Flow:** 380 L/min (100.4 US gpm)
**Max Pressure:** 350 bar (5100 psi)
**Series:** SDS380 Series
**Application Areas:**
- Material Handling
- Construction and Earth Moving
- Agriculture
- Industrial Vehicles
**Applicable Models:**
- Telehandler
- Forklift
- All Terrain Crane
- Stacker
- Aerial Platform
- Motor Grader
- Mini-Excavator
- Skid Steer Loader
- Wheel Loader
- Tractor and Front-End Loader
- Harvester
The SDS380 valve is designed for durability and reliability in harsh operating conditions. Its compact design allows for easy integration into existing systems, while its modular construction provides flexibility for customization. Whether you need a single directional valve or a complete hydraulic system, the SDS380 series offers a reliable solution for your demanding applications.
