DCV58 Solenoid 1 Spool Valve: The Key to Enhancing Your Hydraulic Systems

控制方式:电磁

路数:1 联

额定流量:60 L/min (15.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G3/4接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:DCV58系列分块式方向阀

Packagingsize:27*20*17

Grossweight:6.50 kg

库存: 有货

描述

DCV58 Solenoid 1 Spool Valve: The Key to Enhancing Your Hydraulic Systems

DCV58 Solenoid 1 Spool Valve: The Key to Enhancing Your Hydraulic Systems drawing image

Introducing the DCV58 Solenoid 1 Spool Valve, a high-performance hydraulic component designed to enhance the efficiency and control of your hydraulic systems. With a rated flow of 60 L/min and a maximum pressure of 350 bar, this valve ensures optimal flow and pressure regulation in various applications.

DCV58系列分块式方向阀参数
控制方式	电磁, 电磁和手动
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	分片阀
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量	40 L/min (10.5 US gpm)
最大压力	350 bar (5100 psi)
进油口	G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹
出油口	G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹
接口尺寸	G1/2接口, M22×1.5螺纹, SAE 10接头, 1/2 NPT螺纹

**DCV58 Solenoid 1 Spool Valve**

The DCV58 Solenoid 1 Spool Valve is a sectional valve featuring solenoid control for precise and reliable operation. It is ideally suited for applications in construction machinery, industrial vehicles, and agriculture. With its robust construction and high-quality materials, this valve ensures long-lasting performance and durability.

**Key Features:**

* Control Method: Solenoid
* Section: 1 Section
* Structure Type: Sectional valve
* Rated Flow: 60 L/min (15.8 US gpm)
* Max Pressure: 350 bar (5100 psi)
* Operating Viscosity Range: 15 - 75 mm²/s (15 cSt to 75 cSt)
* Ambient Temperature Range: -40°C to +80°C (-40°F to +176°F)
* Spool: 1 Spool
* Series: DCV58 Series
* Application Area: MATERIAL HANDLING,CONSTRUCTION AND EARTH MOVING,AGRICULTURE,INDUSTRIAL VEHICLES
* Applicable Model: TELEHANDLER,FORKLIFT,ALL TERRAIN CRANE,STACKER,AERIAL PLATFORM,MOTOR GRADER,MIDI-EXCAVATOR,MINI-EXCAVATOR,SKID STEER LOADER,COMPACT WHEEL LOADER

The DCV58 Solenoid 1 Spool Valve is a versatile and efficient hydraulic component that offers exceptional control and performance. It is meticulously designed to meet the demands of modern hydraulic systems in various industries.
