Solenoid Operated Control Valve Customize Electro-hydraulic 2 Spool Sectional Directional Valves

控制方式:电液控

路数:2 联

额定流量:100 L/min (26.5 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G3/4接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:DCV100系列 分块式方向阀

Packagingsize:41*30*16

Grossweight:23.00 kg

库存: 有货

897 次查看了此产品

Solenoid Operated Control Valve Customize Electro-hydraulic 2 Spool Sectional Directional Valves

Solenoid Operated Control Valve Customize Electro-hydraulic 2 Spool Sectional Directional Valves

Solenoid Operated Control Valve Customize Electro-hydraulic 2 Spool Sectional Directional Valves drawing image

This is a high-performance, customizable electro-hydraulic 2-spool sectional directional valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. It features a rated flow of 100 L/min and a maximum pressure of 350 bar, making it suitable for a wide range of heavy-duty machinery.

DCV100系列 分块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 软轴, 一控二手柄控制, 手控+一控二, 手动和电液控制, 电动马达, 电液比例与电磁控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 分片阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 100 L/min (26.5 US gpm)
最大压力 315 bar (4600 psi)
进油口 G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 3/4 NPT螺纹
出油口 G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 3/4 NPT螺纹
接口尺寸 G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 3/4 NPT螺纹

This 2-section sectional valve features a robust design and reliable performance. Its electro-hydraulic control method ensures precise and responsive operation. The valve is rated for a maximum flow rate of 100 L/min (26.5 US gpm) and a maximum pressure of 350 bar (5100 psi), making it suitable for a variety of heavy-duty applications. Its operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) ensures reliable operation in a wide range of temperature conditions. The valve is designed for use in a variety of equipment, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, and skid steer loaders. Its compact size and modular design make it easy to install and integrate into existing systems.
