Hydraulic Breaker Valve 3-Spool Hydraulic Valve | DCV60 Model | Factory Direct & Customizable

控制方式:软轴

路数:3 联

额定流量:60 L/min (15.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G3/4接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:DCV60系列 分块式方向阀

Packagingsize:29*35*17

Grossweight:19.00 kg

库存: 有货

925 次查看了此产品

Hydraulic Breaker Valve 3-Spool Hydraulic Valve | DCV60 Model | Factory Direct & Customizable

Hydraulic Breaker Valve 3-Spool Hydraulic Valve | DCV60 Model | Factory Direct & Customizable

Hydraulic Breaker Valve 3-Spool Hydraulic Valve | DCV60 Model | Factory Direct & Customizable drawing image

The DCV60 3-Spool Hydraulic Breaker Valve is a heavy-duty, customizable valve designed for use in construction, material handling, and industrial applications. This valve offers high flow rates and pressure ratings, making it suitable for demanding operations.

DCV60系列 分块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁和手动, 电磁+一控二, 手控+一控二, 电动马达
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 分片阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 60 L/min (15.8 US gpm)
最大压力 315 bar (4600 psi), 350 bar (5100 psi)
进油口 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
出油口 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
接口尺寸 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹

The DCV60 3-Spool Hydraulic Breaker Valve is a sectional valve designed for use in a variety of heavy-duty applications, including construction, material handling, and industrial equipment. The valve features a 3-spool design with a rated flow of 60 L/min (15.8 US gpm) and a maximum pressure rating of 350 bar (5100 psi). It is available with cable control and is customizable to meet specific requirements. The valve is suitable for use in telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. This valve is built to withstand demanding operating conditions and offers high reliability and durability. It is available directly from the factory and can be customized to meet specific requirements.
