Source Your DCV100 Directional Control Valves from a Trusted Manufacturer

控制方式:手控

路数:2 联

额定流量:100 L/min (26.5 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G3/4接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:DCV100系列分块式方向阀

Packagingsize:22*35*14

Grossweight:18.00 kg

库存: 有货

描述

Source Your DCV100 Directional Control Valves from a Trusted Manufacturer

Source Your DCV100 Directional Control Valves from a Trusted Manufacturer drawing image

The DCV100 Directional Control Valve is a high-performance hydraulic valve designed for a wide range of applications in construction, industrial, agriculture, and material handling industries. With a rated flow of 100 L/min (26.5 US gpm) and a maximum pressure of 350 bar (5100 psi), it provides reliable and efficient flow control in demanding hydraulic systems.

DCV100系列分块式方向阀参数
控制方式	手控, 气控, 电气控, 电液控, 电磁, 液控, 软轴, 一控二手柄控制, 手控+一控二, 手动和电液控制, 电动马达, 电液比例与电磁控制
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	分片阀
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量	100 L/min (26.5 US gpm)
最大压力	315 bar (4600 psi)
进油口	G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 3/4 NPT螺纹
出油口	G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 3/4 NPT螺纹
接口尺寸	G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 3/4 NPT螺纹

**DCV100 Directional Control Valve**

**Control Method:** Manual
**Section:** 2 Section
**Structure Type:** Sectional valve
**Rated Flow:** 100 L/min (26.5 US gpm)
**Max Pressure:** 350 bar (5100 psi)
**Operating Viscosity Range:** 15 - 75 mm²/s (15 cSt to 75 cSt)
**Ambient Temperature Range:** -40°C to +60°C (-40°F to +140°F)
**Spool:** 2 Spool
**Series:** DCV100 Series

**Application Area:**
- MATERIAL HANDLING
- CONSTRUCTION AND EARTH MOVING
- AGRICULTURE
- INDUSTRIAL VEHICLES

**Applicable Model:**
- TELEHANDLER
- FORKLIFT
- ALL TERRAIN CRANE
- STACKER
- AERIAL PLATFORM
- MOTOR GRADER
