3 Way Spool Valve Hydraulic Source Directly & Save: P40 Hydraulic Valves from the Manufacturer

控制方式:手控+一控二

路数:3 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:24*21*13

Grossweight:7.00 kg

库存: 有货

988 次查看了此产品

3 Way Spool Valve Hydraulic Source Directly & Save: P40 Hydraulic Valves from the Manufacturer

3 Way Spool Valve Hydraulic Source Directly & Save: P40 Hydraulic Valves from the Manufacturer

3 Way Spool Valve Hydraulic Source Directly & Save: P40 Hydraulic Valves from the Manufacturer drawing image

The P40 series 3 Way Spool Valve is a high-performance hydraulic valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This robust monoblock valve offers reliable operation and high flow rates, making it ideal for demanding tasks.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

This 3 Way Spool Valve, part of the P40 series, is a direct-sourced product from our factory. We are a leading manufacturer of hydraulic products, offering global distribution, OEM, private labeling, customization, and wholesale options. This valve features a 3-section design with manual and joystick control options, a rated flow of 40 L/min, a maximum pressure of 250 bar, and an operating viscosity range of 15-75 mm²/s. It is suitable for various applications including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. Contact us today to learn more about our factory wholesale and distribution opportunities for this high-quality hydraulic valve.
