The SD25 Electro-hydraulic Directional Valve is a high-quality, monoblock valve designed for heavy-duty applications in material handling, construction, agriculture, and industrial vehicles. With a rated flow of 240 L/min and a max pressure of 315 bar, this valve is suitable for a wide range of equipment, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders.
| SD25系列 分块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 电液控, 液控 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 分片阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联 |
| 工作粘度范围 | 12 - 400 mm²/s (12 cSt to 400 cSt) |
| 额定流量 | 240 L/min (63.4 US gpm) |
| 最大压力 | 315 bar (4600 psi) |
| 进油口 | G1接口, SAE 16接头 |
| 出油口 | G1-1/4接口, SAE 16接头 |
| 接口尺寸 | G1接口, G1-1/4接口, SAE 12接头 |
The SD25 Series Electro-hydraulic Directional Valve is a robust and reliable solution for controlling hydraulic systems in demanding applications. Featuring a monoblock construction, it offers high flow rates and pressure capabilities for efficient operation. The valve is designed for ease of installation and maintenance. Its wide operating temperature range (-40°C to +80°C) ensures reliable performance in various environmental conditions. The SD25 valve is suitable for various applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders, making it an ideal choice for manufacturers and suppliers of construction, agricultural, and industrial equipment.
