DCV60 Hydraulic 2 Spool Sectional Directional Valve with Electric Motor

控制方式:电动马达

路数:2 联

额定流量:60 L/min (15.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:分块式方向阀

产品系列:DCV60系列 分块式方向阀

Packagingsize:22.5*34.05*18.85

Grossweight:20.50 kg

库存: 有货

12 次查看了此产品

DCV60 Hydraulic 2 Spool Sectional Directional Valve with Electric Motor

DCV60 Hydraulic 2 Spool Sectional Directional Valve with Electric Motor

DCV60 Hydraulic 2 Spool Sectional Directional Valve with Electric Motor drawing image

High-performance DCV60 series 2-spool sectional directional valve featuring electric motor control, designed for precise flow management up to 60 L/min and pressures up to 315 bar in demanding mobile and industrial applications.

DCV60系列 分块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁和手动, 电磁+一控二, 手控+一控二, 电动马达
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 分片阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 60 L/min (15.8 US gpm)
最大压力 315 bar (4600 psi), 350 bar (5100 psi)
进油口 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
出油口 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
接口尺寸 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹

As a leading large-scale hydraulic manufacturer, we provide the DCV60 Series 2 Spool Sectional Directional Valve, specifically engineered for precision and durability. This electric motor-controlled valve supports a rated flow of 60 L/min (15.8 US gpm) and handles maximum pressures up to 315 bar (4600 psi), making it suitable for tractors, forklifts, skid steer loaders, and mini-excavators. We offer comprehensive manufacturing solutions including OEM, private labeling, and custom engineering to meet specific regional requirements. Our factory supply chain is optimized for bulk wholesale, ensuring competitive pricing for global markets. We are actively seeking long-term partnerships with distributors, wholesalers, agents, and traders worldwide. Whether you need specialized configurations for agricultural harvesters or heavy-duty construction earth-moving equipment, our factory-direct wholesale model provides the reliability and technical support your business requires.
