The DCV60-G34 Series 3 Way Valve is a customizable hydraulic valve designed for various applications in construction, agriculture, material handling, and industrial vehicles. It offers OEM and ODM services, providing tailored solutions for your specific needs.
| DCV60系列 分块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁和手动, 电磁+一控二, 手控+一控二, 电动马达 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 分片阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 60 L/min (15.8 US gpm) |
| 最大压力 | 315 bar (4600 psi), 350 bar (5100 psi) |
| 进油口 | G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
| 出油口 | G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
| 接口尺寸 | G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
The DCV60-G34 Series is a high-performance 3 way valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. With a rated flow of 60 L/min and a max pressure of 350 bar, this valve provides reliable operation in a wide range of environments. This valve features a sectional structure and offers customization options through OEM and ODM services, allowing you to tailor it to your specific requirements. The DCV60-G34 Series is compatible with various machines, including telehandlers, forklifts, motor graders, mini excavators, skid steer loaders, compact wheel loaders, harvesters, seeding machines, forestry trailers, and balers. Its robust design and high-quality materials ensure long-lasting performance and reliability. Contact us today to discuss your specific requirements and explore the customization possibilities offered by the DCV60-G34 Series.
