Hydraulic Series Solenoid Valve Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct

控制方式:手控

路数:2 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:SAE 8接头

出油口:SAE 8接头

接口尺寸:SAE 8接头

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:23*18*13

Grossweight:4.80 kg

库存: 有货

766 次查看了此产品

Hydraulic Series Solenoid Valve Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct

Hydraulic Series Solenoid Valve Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct

Hydraulic Series Solenoid Valve Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct drawing image

Our P40-U34-2OT Series solenoid valve is a high-quality, durable, and reliable hydraulic valve designed for a wide range of applications in construction, material handling, agriculture, and industrial vehicles. We offer factory direct wholesale pricing for bulk orders.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

This 2-section monoblock valve features a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure rating of 250 bar (3600 psi). It is designed for use with hydraulic fluids with a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can operate in ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve is available for various applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. As a manufacturer, we offer a variety of options including OEM, private labeling, customization, and wholesale pricing. We are also actively seeking distributors, wholesalers, agents, and traders to expand our global reach. Contact us today for more information and a competitive quote.
