The 7-Spool Hydraulic Valve from our P40 Series offers a compact and reliable solution for a wide range of applications. This monoblock valve features manual control, a rated flow of 40 L/min, and a maximum pressure of 250 bar. We provide OEM, ODM, private label, and customization services to tailor the valve to your specific needs.
| P40系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
This 7-Spool Hydraulic Valve is designed for demanding applications in industries such as material handling, construction, and agriculture. It features a compact monoblock design, manual control, and a rated flow of 40 L/min. The valve can handle pressures up to 250 bar and is suitable for a wide range of operating temperatures. We offer comprehensive OEM and ODM services, including customization, private labeling, and manufacturing. This allows us to tailor the valve to your specific requirements and provide you with a cost-effective solution. Contact us today to discuss your project and explore how our 7-Spool Hydraulic Valve can meet your needs.
