4 Way Hydraulic Valve Source Your SD4 Directional Control Valves from a Trusted Manufacturer

控制方式:手控

路数:1 联

额定流量:45 L/min (11.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/8接口

出油口:G3/8接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:SD4系列单块式方向阀

Packagingsize:13*22*13

Grossweight:3.50 kg

库存: 有货

描述

4 Way Hydraulic Valve Source Your SD4 Directional Control Valves from a Trusted Manufacturer

4 Way Hydraulic Valve Source Your SD4 Directional Control Valves from a Trusted Manufacturer drawing image

This is a reliable and durable 4-way hydraulic directional control valve (SD4 series) designed for demanding applications in construction, agriculture, and material handling. It features a compact monoblock design, manual control, and a rated flow of 40 L/min.

SD4系列单块式方向阀参数
控制方式	手控
路数	1 联
额定流量	40 L/min (10.5 US gpm)
最大压力	250 bar (3600 psi), 305 bar (4400 psi)
进油口	G3/8接口, SAE 6接头
出油口	G3/8接口, SAE 6接头
接口尺寸	G3/8接口, SAE 6接头
联数	1联
结构类型	整体阀
环境温度范围	-40°C to +60°C (-40°F to +140°F)
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)

The SD4 Series 4-Way Hydraulic Valve is a manual, monoblock valve offering a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 230 bar (3300 psi). Its robust construction and wide operating temperature range (-40°C to +80°C) make it suitable for various demanding applications. This valve is perfect for use in a variety of equipment, including telehandlers, forklifts, cranes, excavators, and loaders, making it a versatile solution for a wide range of industries.
