Adjustable Pressure Controller SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation

控制方式:手控

路数:1 联

额定流量:45 L/min (11.8 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/8接口

出油口:G3/8接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:SD5系列 单块式方向阀

Packagingsize:23*20*12

Grossweight:3.80 kg

库存: 有货

888 次查看了此产品

Adjustable Pressure Controller SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation

Adjustable Pressure Controller SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation

Adjustable Pressure Controller SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation drawing image

The SD5-G38 Adjustable Pressure Controller is a reliable and durable hydraulic valve designed for smooth operation in a wide range of applications. It offers precise pressure control, high flow rate, and robust construction, making it ideal for use in construction equipment, material handling, agriculture, and industrial vehicles.

SD5系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +60°C (-40°F to +140°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 305 bar (4400 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M20×1.5螺纹, SAE 6接头, SAE 8接头, G1-1/2接口
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M20×1.5螺纹, SAE 6接头, SAE 8接头
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, M20×1.5螺纹, SAE 6接头, SAE 8接头

The SD5-G38 Adjustable Pressure Controller is a high-performance hydraulic valve designed for demanding applications. Its monoblock construction provides exceptional strength and durability, while its manual control method allows for precise pressure adjustments. With a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 305 bar (4400 psi), this valve is suitable for a wide range of hydraulic systems. Its wide operating viscosity range and temperature range ensure reliable performance in various environments. The SD5-G38 is designed for use in a variety of applications, including telehandlers, forklifts, cranes, excavators, loaders, tractors, harvesters, and other industrial vehicles. Its robust construction and high performance make it the perfect choice for demanding applications requiring precise pressure control and reliable operation.
