Private Label Manufacturing: P40-G12-G38-3QTW Monoblock Valve with Your Brand

控制方式:手控

路数:3 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列单块式方向阀

Packagingsize:24*21*13

Grossweight:6.90 kg

库存: 有货

描述

Private Label Manufacturing: P40-G12-G38-3QTW Monoblock Valve with Your Brand

Private Label Manufacturing: P40-G12-G38-3QTW Monoblock Valve with Your Brand drawing image

Our P40-G12-G38-3QTW monoblock valve is a high-performance hydraulic component designed to meet the demanding requirements of various industrial and mobile applications. With its sturdy construction, precise control, and customizable options, this valve is an ideal solution for OEMs and system integrators seeking reliable and tailored hydraulic solutions.

P40系列单块式方向阀参数
控制方式	手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	整体阀
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量	40 L/min (10.5 US gpm)
最大压力	250 bar (3600 psi)
进油口	G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口	G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸	G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

**Key Features:**

- Manual control for precise and responsive operation
- 3-section design for versatility and control over multiple hydraulic circuits
- 40 L/min rated flow capacity to handle high flow demands
- 250 bar maximum pressure rating for durability and reliability
- Wide operating viscosity range from 15 to 75 mm²/s for compatibility with various hydraulic fluids
- Temperature range of -40°C to +80°C for operation in extreme environments
- 3 spool options to suit specific application requirements
- P40 series compatibility for interchangeability and ease of integration

**Applications:**

- Material handling equipment
- Construction and earth-moving machinery
- Agricultural vehicles
- Industrial vehicles

**OEM, ODM, and Private Label Services:**

We offer flexible OEM, ODM, and private label services to meet your specific requirements. Our team of experienced engineers can work closely with you to develop and manufacture customized solutions that align with your brand and application needs. Whether you require tailored valve configurations, custom labeling, or complete design and manufacturing services, we have the expertise and capabilities to deliver the ideal solution for your business.
