12v Hydraulic Spool Valve Private Label Hydraulic Valves: Partner with Us to Build Your Brand

控制方式:手控

路数:2 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:23*18*13

Grossweight:6.00 kg

库存: 有货

1280 次查看了此产品

12v Hydraulic Spool Valve Private Label Hydraulic Valves: Partner with Us to Build Your Brand

12v Hydraulic Spool Valve Private Label Hydraulic Valves: Partner with Us to Build Your Brand

12v Hydraulic Spool Valve Private Label Hydraulic Valves: Partner with Us to Build Your Brand drawing image

This 12V Hydraulic Spool Valve offers reliable control for various applications in material handling, construction, agriculture, and industrial vehicles. It features manual control, 2 sections, and a monoblock design. With a flow rate of 40 L/min and a maximum pressure of 250 bar, it provides robust performance. We offer OEM, private label, and customized solutions to meet your specific needs.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

This 12V Hydraulic Spool Valve is a high-performance, reliable control solution for a wide range of applications in industries such as material handling, construction, agriculture, and industrial vehicles. Featuring manual control, 2 sections, and a monoblock design, this valve provides precise and efficient operation. It boasts a flow rate of 40 L/min and a maximum pressure of 250 bar, ensuring robust performance in demanding environments. With an operating viscosity range of 15 - 75 mm²/s and an ambient temperature range of -40°C to +80°C, this valve is designed for diverse conditions. Our expertise in manufacturing, OEM, private label, and custom solutions allows us to tailor this product to your specific requirements. We are committed to delivering high-quality hydraulic valves that meet your exact specifications and contribute to your brand's success.
