Private Label Hydraulic Valves: P40-G12-YW Directional Valve with Your Brand

控制方式:手控

路数:1 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列单块式方向阀

Packagingsize:23*16*11

Grossweight:3.00 kg

库存: 有货

描述

Private Label Hydraulic Valves: P40-G12-YW Directional Valve with Your Brand

Private Label Hydraulic Valves: P40-G12-YW Directional Valve with Your Brand drawing image

Introducing our Private Label Hydraulic Directional Valve P40-G12-YW, engineered with precision to meet the demands of global markets. As a leading manufacturer, we offer OEM, ODM, private branding, and customization services to cater to your unique requirements.

P40系列单块式方向阀参数
控制方式	手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	整体阀
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量	40 L/min (10.5 US gpm)
最大压力	250 bar (3600 psi)
进油口	G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口	G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸	G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

Our P40-G12-YW Directional Valve boasts exceptional performance with a rated flow of 40 L/min and a max pressure of 250 bar. Its monoblock construction ensures durability and reliability in demanding applications. With a wide operating viscosity range and temperature range, this valve is suitable for a diverse range of industries. We understand the importance of customization and offer tailored solutions to meet your specific needs, ensuring your brand stands out in the marketplace.
