Control Unit With Solenoids P80 Valve Distribution Opportunities: Profitable Partnerships Await

控制方式:电磁

路数:2 联

额定流量:80 L/min (21.2 US gpm)

最大压力:200 bar (2900 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P80系列 单块式方向阀

Packagingsize:37*18*11

Grossweight:9.50 kg

库存: 有货

1382 次查看了此产品

Control Unit With Solenoids P80 Valve Distribution Opportunities: Profitable Partnerships Await

Control Unit With Solenoids P80 Valve Distribution Opportunities: Profitable Partnerships Await

Control Unit With Solenoids P80 Valve Distribution Opportunities: Profitable Partnerships Await drawing image

Our P80 Series Control Unit with Solenoids is a high-performance, reliable hydraulic valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. With its 2-section monoblock design, 80 L/min flow rate, and 250 bar pressure rating, this valve offers exceptional control and efficiency.

P80系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 手控+一控二
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 80 L/min (21.2 US gpm)
最大压力 315 bar (4600 psi)
进油口 G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
出油口 G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
接口尺寸 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, 1/2 NPT螺纹, 3/4 NPT螺纹

This Control Unit with Solenoids is part of our P80 Series and features a 2-section monoblock design. It boasts a flow rate of 80 L/min and a maximum pressure rating of 250 bar, making it suitable for various applications in material handling, construction, agriculture, and industrial vehicles. The valve operates with a solenoid control method and features a 2-spool design. It's designed to withstand demanding environments with its -40°C to +80°C operating temperature range and is compatible with a wide viscosity range of 15 - 75 mm²/s. We offer this valve as a manufactured product, OEM component, private label item, and custom solution. We're actively seeking distributors, wholesalers, dealers, and traders to expand our global reach and offer our high-quality products to a wider audience. Contact us today to explore profitable partnership opportunities.
