Hydraulic Valve 1p40 P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution

控制方式:手控

路数:2 联

额定流量:80 L/min (21.2 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G3/4接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P80系列 单块式方向阀

Packagingsize:26*18*11

Grossweight:8.20 kg

库存: 有货

814 次查看了此产品

Hydraulic Valve 1p40 P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution

Hydraulic Valve 1p40 P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution

Hydraulic Valve 1p40 P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution drawing image

The P80 Series Hydraulic Valve is a 2-section, manual control monoblock valve with a rated flow of 80 L/min and a max pressure of 250 bar. This versatile valve is designed for use in various applications including construction, agriculture, material handling, and industrial vehicles.

P80系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 手控+一控二
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 80 L/min (21.2 US gpm)
最大压力 315 bar (4600 psi)
进油口 G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
出油口 G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
接口尺寸 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, 1/2 NPT螺纹, 3/4 NPT螺纹

The P80 Series Hydraulic Valve is a high-performance, reliable valve designed for demanding applications. It features a robust monoblock construction, 2 sections for precise control, and a manual control method. This valve is suitable for a wide range of equipment, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, tractors, harvesters, bale wrappers, backhoes, seeding machines, sprayers, and balers. It offers a rated flow of 80 L/min and a max pressure of 250 bar, making it ideal for various hydraulic systems. Its operating viscosity range is 15-75 mm²/s, and it can withstand ambient temperatures from -40°C to +80°C. The valve is equipped with a 2-spool configuration, providing flexibility for different control needs. Whether you require a hydraulic valve for construction, agriculture, material handling, or industrial vehicles, the P80 Series offers a robust and reliable solution.
