P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory

控制方式:手控

路数:2 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40-XNHJ系列 单块式方向阀

Packagingsize:23*18*11

Grossweight:5.00 kg

库存: 有货

412 次查看了此产品

P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory

P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory

P40-XNHJ Monoblock Directional Valve: Wholesale Prices from the Factory drawing image

High-quality P40-XNHJ series monoblock directional hydraulic valves, offering 40 L/min flow rate and 250 bar max pressure. Ideal for material handling, construction, agriculture, and industrial vehicles. Factory direct wholesale prices available.

P40-XNHJ系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 手控+一控二
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
结构类型 整体阀
环境温度范围 -40°C to +80°C (-40°F to +176°F)
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)

The P40-XNHJ Monoblock Directional Valve is a robust and reliable hydraulic control solution, perfect for a wide range of applications. This 2-section, manual control valve boasts a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). Its operating viscosity range is 15-75 mm²/s (15 cSt to 75 cSt), and it's designed to withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). Featuring a 2-spool design, this valve is ideal for various equipment including forklifts, telehandlers, skid steer loaders, tractors, mini-excavators, backhoes, balers, harvesters, and sprayers.

As a leading **manufacturer** and factory supplier of hydraulic valves, we offer **wholesale** prices directly from our factory. We also provide **OEM**, **private labeling** and **customization** services to meet your specific needs. We are actively seeking reliable **distributors**, **wholesalers**, **agents**, and **trading companies** globally to partner with us and expand our market reach. Contact us today to discuss your requirements and explore mutually beneficial collaborations. We offer competitive pricing and excellent quality for all your **hydraulic valve** needs. Choose our **factory direct** supply for superior value and guaranteed satisfaction. Our **P40 valve** is a high-performance solution you can trust.
