Adjustable Control Valve P40-U78 Valve: Compatible Fluids, Operating Conditions & Maintenance

控制方式:手控

路数:5 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:SAE 10接头

出油口:SAE 10接头

接口尺寸:SAE 10接头

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:28*23*13

Grossweight:9.80 kg

库存: 有货

910 次查看了此产品

Adjustable Control Valve P40-U78 Valve: Compatible Fluids, Operating Conditions & Maintenance

Adjustable Control Valve P40-U78 Valve: Compatible Fluids, Operating Conditions & Maintenance

Adjustable Control Valve P40-U78 Valve: Compatible Fluids, Operating Conditions & Maintenance drawing image

The P40-U78 Adjustable Control Valve is a 5-section, monoblock valve designed for use in a variety of construction, material handling, and industrial equipment. With a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve is suitable for demanding applications.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

This P40-U78 Adjustable Control Valve is a high-performance, 5-section, monoblock valve that is designed for use in a variety of demanding applications. This valve is suitable for use in a variety of applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini excavators, skid steer loaders, and compact wheel loaders. The P40-U78 valve is built with quality materials and is designed for a long service life. With its robust construction and durable components, this valve is capable of withstanding high pressures and demanding operating conditions. The P40-U78 valve is also easy to install and maintain, which can help to reduce downtime and increase productivity. The valve can be used with a variety of hydraulic fluids and is compatible with a wide range of operating conditions. This valve is a reliable and efficient solution for a variety of applications.
