The P40-U78 Manual 3 Spool Valve is a high-performance hydraulic relief valve designed for a wide range of applications, including material handling, construction, agriculture, and industrial vehicles. This robust valve is available for private label, OEM, and custom manufacturing, offering flexibility and tailored solutions for diverse needs.
| P40系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
This manual 3-spool valve from the P40 series is a robust and reliable solution for hydraulic systems. It features a monoblock structure and is rated for a flow of 40 L/min and a maximum pressure of 250 bar. The valve's operating viscosity range is 15 to 75 mm²/s, and it can operate in ambient temperatures from -40°C to +80°C. Suitable for a variety of applications, including telehandlers, forklifts, cranes, excavators, loaders, dumpers, drill rigs, concrete pumps, and more. This valve is ideal for manufacturers seeking private label, OEM, or custom solutions for their hydraulic systems.
