Single Spool Hydraulic Valve With Power Beyond P40-G12-G38-OT-QTW Valve: OEM and ODM

控制方式:手控

路数:2 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:23*18*13

Grossweight:4.90 kg

库存: 有货

872 次查看了此产品

Single Spool Hydraulic Valve With Power Beyond P40-G12-G38-OT-QTW Valve: OEM and ODM

Single Spool Hydraulic Valve With Power Beyond P40-G12-G38-OT-QTW Valve: OEM and ODM

Single Spool Hydraulic Valve With Power Beyond P40-G12-G38-OT-QTW Valve: OEM and ODM drawing image

The P40 Series Single Spool Hydraulic Valve with Power Beyond is a versatile and robust valve designed for various applications including construction, material handling, agriculture, and industrial vehicles. This valve features a compact monoblock design, high flow rate, and durable construction, making it ideal for demanding hydraulic systems.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

The P40 Series Single Spool Hydraulic Valve with Power Beyond is a high-performance hydraulic valve designed for a wide range of applications, including construction equipment, material handling equipment, agriculture machinery, and industrial vehicles. This valve features a 2-section monoblock design with a rated flow of 40 L/min and a maximum pressure of 250 bar, ensuring reliable performance in demanding applications. The valve also offers manual control and is compatible with various operating viscosities and ambient temperatures. This valve is ideal for applications that require a compact, powerful, and efficient hydraulic control solution. It is designed for use with a wide range of hydraulic actuators and systems. The P40 Series Single Spool Hydraulic Valve with Power Beyond is available as an OEM or ODM product, allowing customers to customize the valve to meet their specific needs.
