The P40-G12-G38 5-Spool Hydraulic Directional Valve is a high-performance valve designed for a wide range of applications in material handling, construction, earth moving, agriculture, and industrial vehicles. With its manual control, monoblock valve design, and rated flow of 40 L/min, this valve offers precise and reliable control of hydraulic systems.
| P40系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
The P40-G12-G38 5-Spool Hydraulic Directional Valve is a robust and durable valve that can withstand harsh operating conditions. It features a maximum pressure of 250 bar and an operating viscosity range of 15 - 75 mm²/s. The valve also has a wide ambient temperature range of -40°C to +80°C, making it suitable for use in various environments.
The P40-G12-G38 5-Spool Hydraulic Directional Valve is commonly used in various applications, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, mini excavators, skid steer loaders, compact wheel loaders, and wheel loaders. Its versatility and high performance make it an ideal choice for demanding hydraulic applications.
