Hydraulic Valve Joystick P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor

控制方式:手控

路数:2 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:23*18*13

Grossweight:5.10 kg

库存: 有货

958 次查看了此产品

Hydraulic Valve Joystick P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor

Hydraulic Valve Joystick P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor

Hydraulic Valve Joystick P40-G12-G38-2QTW Monoblock Valve | Manufacturer & Global Distributor drawing image

The P40-G12-G38-2QTW Monoblock Valve is a high-performance hydraulic joystick valve designed for construction and industrial equipment. It features a compact monoblock design, 2 sections, and a rated flow of 40 L/min. This valve is ideal for telehandlers, forklifts, cranes, stackers, and other heavy-duty applications.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

The P40-G12-G38-2QTW Monoblock Valve is a robust and reliable hydraulic valve with manual control. This 2-section valve features a compact monoblock design, making it suitable for applications where space is limited. It has a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure rating of 250 bar (3600 psi). This valve operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). With its 2 spools, this valve is suitable for controlling various hydraulic functions in construction and industrial equipment such as telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. It is specifically designed to meet the demanding requirements of these applications.
