P40 3 Spool Monoblock Directional Valve - Wholesale, OEM & Customization Options

控制方式:电磁+一控二

路数:3 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:30*22*15

Grossweight:10.00 kg

库存: 有货

828 次查看了此产品

P40 3 Spool Monoblock Directional Valve - Wholesale, OEM & Customization Options

P40 3 Spool Monoblock Directional Valve - Wholesale, OEM & Customization Options

P40 3 Spool Monoblock Directional Valve - Wholesale, OEM & Customization Options drawing image

The P40 3 Spool Monoblock Directional Valve is a high-performance hydraulic valve designed for a wide range of applications in material handling, construction, earthmoving, agriculture, and industrial vehicles. With its robust construction and versatile control options, this valve is ideal for demanding environments.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

The P40 3 Spool Monoblock Directional Valve is a reliable and efficient hydraulic component offering both solenoid and joystick control options. This 3-section valve features a robust monoblock design and boasts a rated flow of 40 L/min with a maximum pressure rating of 250 bar. Operating in a wide viscosity range from 15 to 75 mm²/s, this valve can withstand temperatures from -40°C to +80°C. Designed for heavy-duty applications, the P40 series is suitable for various mobile machinery including telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, tractors, and harvesters. We offer wholesale, OEM, and customization options to meet specific requirements. We are actively seeking distributors, wholesalers, agents, and traders to expand our global reach.
