This hydraulic control valve is a reliable and durable solution for a wide range of applications, offering 45 GPM flow rate and 250 bar pressure. Available for customization with OEM and ODM services, it's ideal for material handling, construction, and agricultural equipment.
| P120系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 软轴, 一控二手柄控制, 手控+一控二 |
| 路数 | 1 联, 2 联, 3 联, 4 联 |
| 额定流量 | 120 升/分钟 (31.7 美制加仑/分钟) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 3/4 NPT螺纹, 1 NPT螺纹, M36×2螺纹 |
| 出油口 | G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹 |
| 接口尺寸 | G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 1 NPT螺纹, M36×2螺纹 |
| 联数 | 1联, 2联, 3联, 4联 |
| 结构类型 | 整体阀 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
This hydraulic control valve, part of the P120 series, delivers a flow rate of 45 GPM (120 L/min) and a maximum pressure of 250 bar (3600 psi). It features a robust monoblock design and operates with manual control. This valve is suitable for various applications, including material handling, construction, earthmoving, agriculture, and industrial vehicles. Our company offers a comprehensive range of services including manufacturing, OEM and ODM customization, and wholesale. We are actively seeking distributors, wholesalers, agents, and traders to expand our global reach.
