SD5 Series 3/8 Hydraulic Ball Valve is a high-performance, solenoid-operated valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. It features a robust monoblock construction, rated flow of 40 L/min, and max pressure of 305 bar. We offer OEM manufacturing, private label, and custom options to meet your specific needs.
| SD5系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +60°C (-40°F to +140°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 305 bar (4400 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M20×1.5螺纹, SAE 6接头, SAE 8接头, G1-1/2接口 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M20×1.5螺纹, SAE 6接头, SAE 8接头 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, M20×1.5螺纹, SAE 6接头, SAE 8接头 |
The SD5 Series 3/8 Hydraulic Ball Valve is a compact and reliable solution for controlling hydraulic systems in a wide range of applications. Featuring a solenoid control method, this monoblock valve provides a rated flow of 40 L/min and can withstand pressures up to 305 bar. Designed for demanding environments, it operates effectively in ambient temperatures from -40°C to +60°C. We are a leading manufacturer of hydraulic products and offer OEM manufacturing, private label, and custom options to meet your specific requirements. We also welcome distributors, wholesalers, agents, and traders to join our global network.
