Directional Solenoid Valve Hydraulic Monoblock Directional Valve - P80 Series | Wholesale & OEM

控制方式:手控

路数:1 联

额定流量:80 L/min (21.2 US gpm)

最大压力:250 bar (3600 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P80系列 单块式方向阀

Packagingsize:26*15*11

Grossweight:5.00 kg

库存: 有货

945 次查看了此产品

Directional Solenoid Valve Hydraulic Monoblock Directional Valve - P80 Series | Wholesale & OEM

Directional Solenoid Valve Hydraulic Monoblock Directional Valve - P80 Series | Wholesale & OEM

Directional Solenoid Valve Hydraulic Monoblock Directional Valve - P80 Series | Wholesale & OEM drawing image

The P80 Series Directional Solenoid Valve is a high-performance hydraulic monoblock valve designed for a wide range of applications, including material handling, construction, and agriculture. This robust valve features manual control, 1 section, a rated flow of 80 L/min, and a maximum pressure of 250 bar. Available for wholesale and OEM purposes.

P80系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 手控+一控二
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 80 L/min (21.2 US gpm)
最大压力 315 bar (4600 psi)
进油口 G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
出油口 G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
接口尺寸 G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, 1/2 NPT螺纹, 3/4 NPT螺纹

The P80 Series Directional Solenoid Valve is a reliable and efficient hydraulic valve suitable for demanding applications. It features a monoblock construction for durability and compact size, offering a rated flow of 80 L/min and a maximum pressure of 250 bar (3600 psi). The valve operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). This valve is ideal for various equipment, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. We offer wholesale and OEM services to meet the diverse needs of our customers. Contact us today to discuss your specific requirements and explore our range of hydraulic valve solutions.
