Monoblock Directional Control Valve | P80-G12-QTW | Factory Direct & Wholesale

控制方式:手控

路数:1 联

额定流量:80 L/min (21.2 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P80系列单块式方向阀

Packagingsize:26*17*11

Grossweight:5.00 kg

库存: 有货

描述

Monoblock Directional Control Valve | P80-G12-QTW | Factory Direct & Wholesale

Monoblock Directional Control Valve | P80-G12-QTW | Factory Direct & Wholesale drawing image

Our Monoblock Directional Control Valve (P80-G12-QTW) is a high-performance hydraulic component designed for demanding applications in various industries. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), it ensures efficient and reliable fluid control.

P80系列单块式方向阀参数
控制方式	手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 手控+一控二
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	整体阀
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量	80 L/min (21.2 US gpm)
最大压力	315 bar (4600 psi)
进油口	G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
出油口	G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹
接口尺寸	G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, 1/2 NPT螺纹, 3/4 NPT螺纹

**Key Features:**

- Monoblock design for compact and leak-free operation
- Manual control method for precise and responsive valve actuation
- Wide operating viscosity range (15 - 75 mm²/s) for compatibility with various hydraulic fluids
- Extended ambient temperature range (-40°C to +80°C) for use in harsh environments
- Single spool configuration for versatile flow control applications

**Applications:**

- Telehandlers
- Forklifts
- All Terrain Cranes
- Stackers
- Aerial Platforms
- Motor Graders
- Mini and Midi Excavators
- Skid Steer Loaders
- Compact Wheel Loaders

**Industries:**

- Material Handling
- Construction and Earth Moving
- Agriculture
- Industrial Vehicles
