We are a hydraulic product manufacturer specializing in manual 5 spool monoblock valves. Our P40 series valves offer high performance and reliability for various applications in construction, material handling, agriculture, and industrial vehicles. We provide manufacturing, OEM, private labeling, customization, and wholesale services.
| P40系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
This 5-section monoblock valve features manual control and a rated flow of 40 L/min (10.5 US gpm). It is designed to withstand pressures up to 250 bar (3600 psi) and operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). With an ambient temperature range of -40°C to +80°C (-40°F to +176°F), this robust valve is ideal for various applications in construction, material handling, agriculture, and industrial vehicles. As a manufacturer, we offer factory supply, factory wholesale, and OEM services to meet the needs of our global customers.
