The SD11 Series 12V Solenoid Valve is a high-performance, 2-section monoblock directional hydraulic valve designed for a wide range of construction, material handling, and industrial applications. It features pneumatic control, 70 L/min flow rate, and 250 bar pressure rating, making it suitable for demanding operations.
| SD11系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁, 气动和手动 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联 |
| 环境温度范围 | -40°C to +60°C (-40°F to +140°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 70 L/min (18.5 US gpm) |
| 最大压力 | 305 bar (4400 psi), 315 bar (4600 psi) |
| 进油口 | G3/4接口, SAE 12接头 |
| 出油口 | G3/4接口, SAE 12接头 |
| 接口尺寸 | G3/4接口, SAE 12接头 |
This 12V Solenoid Valve (SD11 Series) is a robust and reliable monoblock directional valve engineered for heavy-duty applications. It offers pneumatic control for precise operation and features a 2-section design for versatile control of hydraulic circuits. The valve boasts a high flow rate of 70 L/min (18.5 US gpm) and can withstand pressures up to 250 bar (3600 psi), making it suitable for demanding applications in construction, material handling, and other industries. Its compact size and durable construction make it ideal for integration into various mobile equipment, including telehandlers, forklifts, cranes, excavators, loaders, and more. Available for wholesale and OEM orders.
