Our P40-U34 Series hydraulic valves offer exceptional performance and versatility for various applications. With OEM and ODM services, we can tailor these valves to your specific requirements, including customized designs, private labeling, and tailored solutions.
| P40系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
**P40-U34 Series Hydraulic Valve: Customizable Solutions for Demanding Applications**
**OEM/ODM Services for Tailored Solutions:**
- Custom designs to match your exact specifications
- Private labeling for enhanced brand recognition
- Specialized solutions to meet unique application challenges
**Exceptional Performance and Durability:**
- Manual control for precise operation
- Monoblock construction for ruggedness and reliability
- Rated flow of 40 L/min and maximum pressure of 250 bar
- Operating viscosity range of 15 - 75 mm²/s
- Ambient temperature range of -40°C to +80°C
**Wide Range of Applications:**
- Material handling equipment (e.g., forklifts, telehandlers)
- Construction and earthmoving machinery (e.g., excavators, skid steer loaders)
- Agricultural vehicles (e.g., tractors, harvesters)
- Industrial vehicles (e.g., aerial platforms, motor graders)
