High Pressure DCV20 Series 4 Spool Hydraulic Control Valve

控制方式:手控

路数:4 联

额定流量:20 L/min (5.2 US gpm)

最大压力:315 bar (4600 psi)

进油口:G3/8接口

出油口:G3/8接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:DCV20系列 单块式方向阀

Packagingsize:23*21*11

Grossweight:6.20 kg

库存: 有货

13 次查看了此产品

High Pressure DCV20 Series 4 Spool Hydraulic Control Valve

High Pressure DCV20 Series 4 Spool Hydraulic Control Valve

High Pressure DCV20 Series 4 Spool Hydraulic Control Valve drawing image

The DCV20 Series is a high-pressure 4-spool manual hydraulic directional control valve designed for compact applications, offering a rated flow of 20 L/min and operating capability up to 350 bar. It is ideal for material handling, agriculture, and construction machinery requiring precise manual control.

DCV20系列 单块式方向阀 参数
控制方式 手控, 电液控, 一控二手柄控制, 手控+一控二
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 20 L/min (5.2 US gpm)
最大压力 350 bar (5100 psi)
进油口 G3/8接口, M18×1.5螺纹, SAE 8接头, 3/8 NPT螺纹
出油口 G3/8接口, M18×1.5螺纹, SAE 8接头, 3/8 NPT螺纹
接口尺寸 G3/8接口, M18×1.5螺纹, SAE 8接头, 3/8 NPT螺纹

As a leading large-scale manufacturer of hydraulic components, we proudly present the DCV20 Series 4 Spool Hydraulic Control Valve. Engineered for high-pressure environments (up to 5100 psi), this manual valve provides exceptional reliability and responsive control for equipment such as forklifts, mini-excavators, and tractors. Our factory offers comprehensive manufacturing services including OEM, private labeling (ODM), and custom design to meet specific technical requirements. We specialize in factory-wholesale supplies, ensuring competitive pricing and consistent quality for the global market. We are actively seeking long-term cooperation with distributors, wholesalers, regional agents, and international traders. Whether you need bulk wholesale orders or customized hydraulic solutions for wood splitters, sweepers, or aerial platforms, our factory production lines are equipped to support your business growth with robust logistics and technical support.
