Introducing our P40-G12-G38-2QTW Hydraulic Valves, engineered for superior performance in various industrial applications. These valves feature a robust 2-section monobloc design, delivering exceptional flow rates of up to 40 L/min. With a maximum pressure of 250 bar and a wide operating viscosity range, they ensure reliable operation in demanding environments. These valves are ideal for applications in material handling, construction, agriculture, and industrial vehicles.
| P40系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
Our P40-G12-G38-2QTW Hydraulic Valves are meticulously crafted using high-quality materials and advanced manufacturing techniques. As a leading manufacturer, we offer factory supply and wholesale pricing for bulk orders, ensuring cost-effective solutions for our customers. These valves boast exceptional features such as precise spool control, efficient flow management, and durability in harsh operating conditions. With their compact size and modular design, they seamlessly integrate into various hydraulic systems. Whether you're a distributor, wholesaler, agent, or trader, we invite you to explore our extensive range of hydraulic valves and partner with us for exceptional quality and value.
