Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves

控制方式:手控

路数:3 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:SAE 10接头

出油口:SAE 10接头

接口尺寸:SAE 8接头

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:24*21*13

Grossweight:7.00 kg

库存: 有货

825 次查看了此产品

Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves

Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves

Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves drawing image

Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves are high-quality valves designed for use in various applications, including material handling, construction, agriculture, and industrial vehicles. These valves feature a manual control method, 3-section monoblock valve structure, 40 L/min (10.5 US gpm) rated flow, 250 bar (3600 psi) max pressure, 15 - 75 mm²/s (15 cSt to 75 cSt) operating viscosity range, -40°C to +80°C (-40°F to +176°F) ambient temperature range, and 3 spool. They are suitable for use in various models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, backhoe loaders, tractors, and front-end loaders.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

**Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves**

**Product Overview**

Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves are high-quality valves designed for use in various applications, including material handling, construction, agriculture, and industrial vehicles. These valves feature a manual control method, 3-section monoblock valve structure, 40 L/min (10.5 US gpm) rated flow, 250 bar (3600 psi) max pressure, 15 - 75 mm²/s (15 cSt to 75 cSt) operating viscosity range, -40°C to +80°C (-40°F to +176°F) ambient temperature range, and 3 spool. They are suitable for use in various models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, backhoe loaders, tractors, and front-end loaders.

**Key Features**

* Manual control method
* 3-section monoblock valve structure
* 40 L/min (10.5 US gpm) rated flow
* 250 bar (3600 psi) max pressure
* 15 - 75 mm²/s (15 cSt to 75 cSt) operating viscosity range
* -40°C to +80°C (-40°F to +176°F) ambient temperature range
* 3 spool
* Suitable for use in various models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, backhoe loaders, tractors, and front-end loaders

**Benefits**

* High quality and durable
* Excellent performance
* Long service life
* Competitive price
* Fast delivery
* Excellent customer service

**Applications**

Factory Direct Valves: P40-U78-U34-2OT-YW Monoblock Directional Control Valves are widely used in various applications, including:

* Material handling
* Construction
* Agriculture
* Industrial vehicles

**Manufacturer**

Factory Direct Valves is a leading manufacturer of high-quality hydraulic valves. We have over 10 years of experience in the industry and have a team of experienced engineers and technicians. We are committed to providing our customers with the best possible products and services.

**Factory Supply**

We are a factory-direct supplier, which means that we can offer our products at the most competitive prices. We also have a large inventory of products in stock, which means that we can deliver your orders quickly and efficiently.

**Factory Wholesale**

We offer factory wholesale prices to our customers. This means that you can save money on your purchases when you buy from us. We also offer a variety of discounts and promotions to our customers, which can help you save even more money.

**Contact Us**

If you are interested in learning more about our products or services, please contact us today. We would be happy to answer any of your questions and provide you with a free quote.
