Hydraulic Remote Control Factory Direct Supply: P40-AQF-G38-G12 Monoblock Valve for Wholesale

控制方式:手控

路数:2 联

额定流量:40 L/min (10.5 US gpm)

最大压力:250 bar (3600 psi)

进油口:G1/2接口

出油口:G1/2接口

接口尺寸:G3/8接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P40系列 单块式方向阀

Packagingsize:23*18*13

Grossweight:5.50 kg

库存: 有货

918 次查看了此产品

Hydraulic Remote Control Factory Direct Supply: P40-AQF-G38-G12 Monoblock Valve for Wholesale

Hydraulic Remote Control Factory Direct Supply: P40-AQF-G38-G12 Monoblock Valve for Wholesale

Hydraulic Remote Control Factory Direct Supply: P40-AQF-G38-G12 Monoblock Valve for Wholesale drawing image

The P40-AQF-G38-G12 Monoblock Valve is a high-performance hydraulic valve designed for remote control applications. It is available for wholesale directly from the manufacturer, offering competitive pricing and reliable quality.

P40系列 单块式方向阀 参数
控制方式 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制
路数 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 整体阀
联数 1联, 2联, 3联, 4联, 5联, 6联, 7联
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量 40 L/min (10.5 US gpm)
最大压力 250 bar (3600 psi)
进油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
出油口 G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹
接口尺寸 G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹

This 2-section monoblock valve features a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). It is suitable for a wide range of applications including material handling, construction, agriculture, and industrial vehicles. The valve is designed for manual control and features a 2-spool configuration. It is manufactured to the highest standards, ensuring durability and reliability. As a direct factory supplier, we offer competitive pricing and flexible order options, including OEM, ODM, and customization. We are also actively seeking distributors, wholesalers, agents, and traders globally. Contact us today to discuss your specific requirements and explore the benefits of partnering with our factory.
