The P120-G1-OT Hydraulic Spool Block is a 3-section monoblock valve with manual control, rated for 120 L/min flow and 250 bar pressure. It is ideal for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. We are the manufacturer and offer direct-from-factory advantages, including wholesale pricing.
| P120系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 软轴, 一控二手柄控制, 手控+一控二 |
| 路数 | 1 联, 2 联, 3 联, 4 联 |
| 额定流量 | 120 升/分钟 (31.7 美制加仑/分钟) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 3/4 NPT螺纹, 1 NPT螺纹, M36×2螺纹 |
| 出油口 | G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹 |
| 接口尺寸 | G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 1 NPT螺纹, M36×2螺纹 |
| 联数 | 1联, 2联, 3联, 4联 |
| 结构类型 | 整体阀 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
This P120-G1-OT Hydraulic Spool Block is designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. It features 3 spools, a 3-section monoblock valve design, and manual control for precise operation. With a rated flow of 120 L/min and a maximum pressure rating of 250 bar, this spool block delivers reliable performance in various heavy-duty applications. We are the manufacturer, offering direct-from-factory advantages, including competitive wholesale pricing. Contact us today to discuss your specific requirements and explore our factory supply options.
