Our P40 Series Counter Balance Hydraulic Valve offers customizable solutions for various applications in material handling, construction, agriculture, and industrial vehicles. This high-quality, monoblock valve is available for OEM, ODM, and private label needs.
| P40系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 电磁+一控二, 手控+一控二, 电磁与软轴控制 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 40 L/min (10.5 US gpm) |
| 最大压力 | 250 bar (3600 psi) |
| 进油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 出油口 | G3/8接口, G1/2接口, M18×1.5螺纹, M22×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
| 接口尺寸 | G3/8接口, G1/2接口, M18×1.5螺纹, SAE 8接头, SAE 10接头, 3/8 NPT螺纹, 1/2 NPT螺纹 |
The P40 Series Counter Balance Hydraulic Valve is a robust and reliable solution for a wide range of applications. It is a 3-section, monoblock valve with a rated flow of 40 L/min and a maximum pressure of 250 bar. The valve features a manual control method and operates within a viscosity range of 15 - 75 mm²/s. We offer bespoke hydraulic solutions with customizable options to meet your specific needs. Our manufacturing expertise allows us to provide OEM, ODM, and private label services to cater to diverse market requirements. Contact us today to discuss your specific needs and explore how our P40 Series Counter Balance Hydraulic Valve can enhance your machinery performance.
