Hydraulic Multi-way Valve 2-Spool Hydraulic Valve | P120 Model | Factory Direct & Customizable

控制方式:手控

路数:2 联

额定流量:120 升/分钟 (31.7 美制加仑/分钟)

最大压力:250 bar (3600 psi)

进油口:G1接口

出油口:G1接口

接口尺寸:G1接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P120系列单块式方向阀

Packagingsize:30*39*17

Grossweight:19.00 kg

库存: 有货

描述

Hydraulic Multi-way Valve 2-Spool Hydraulic Valve | P120 Model | Factory Direct & Customizable

Hydraulic Multi-way Valve 2-Spool Hydraulic Valve | P120 Model | Factory Direct & Customizable drawing image

The P120 Series Hydraulic Multi-way Valve is a 2-spool, monoblock valve designed for construction, material handling, and industrial applications. With a rated flow of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi), it's ideal for demanding tasks.

P120系列单块式方向阀参数
控制方式	手控, 软轴, 一控二手柄控制, 手控+一控二
路数	1 联, 2 联, 3 联, 4 联
额定流量	120 升/分钟 (31.7 美制加仑/分钟)
最大压力	250 bar (3600 psi)
进油口	G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 3/4 NPT螺纹, 1 NPT螺纹, M36×2螺纹
出油口	G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹
接口尺寸	G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 1 NPT螺纹, M36×2螺纹
联数	1联, 2联, 3联, 4联
结构类型	整体阀
环境温度范围	-40°C to +80°C (-40°F to +176°F)
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)

This robust Hydraulic Multi-way Valve offers manual control, a 2-section design, and a reliable monoblock structure. Featuring a rated flow of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi), it is suitable for various applications like telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. The valve operates in a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and withstands ambient temperatures from -40°C to +80°C (-40°F to +176°F).
