2 Spool Directional Control Valve QSF32 Series

控制方式:负载敏感比例

路数:2 联

额定流量:250 L/min (66 US gpm)

最大压力:230 bar (3300 psi)

进油口:M36×2螺纹

出油口:M36×2螺纹

接口尺寸:M18×1.5螺纹

品牌:BXHS

所属类别:清扫车阀门

产品系列:QSF32系列 清扫车阀门

Packagingsize:27*27*20

Grossweight:35.00 kg

库存: 有货

14 次查看了此产品

2 Spool Directional Control Valve QSF32 Series

2 Spool Directional Control Valve QSF32 Series

2 Spool Directional Control Valve QSF32 Series drawing image

The QSF32 Series is a high-performance 2-spool load-sensing proportional directional control valve designed for heavy-duty applications. It offers a rated flow of 250 L/min and a maximum pressure of 230 bar, providing precise control for construction, agricultural, and material handling equipment.

QSF32系列 清扫车阀门 参数
控制方式 电磁, 负载敏感比例
路数 1 联, 2 联, 3 联
环境温度范围 -40°C to +80°C (-40°F to +176°F)
结构类型 分片阀
联数 1联, 2联, 3联
工作粘度范围 12 - 400 mm²/s (12 cSt to 400 cSt)
额定流量 250 L/min (66 US gpm)
最大压力 250 bar (3600 psi)
进油口 G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹
出油口 G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹
接口尺寸 G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹

As a professional hydraulic manufacturer, we specialize in the production of the QSF32 Series 2-spool load-sensing directional control valves. Engineered for efficiency and durability, this series is compatible with wheel loaders, excavators, tractors, and telehandlers, ensuring seamless operation in demanding environments. We offer comprehensive global manufacturing services, including OEM, ODM, and private labeling, tailored to your specific mechanical requirements. Whether you require customized flow configurations or bulk wholesale orders, our factory-direct supply chain guarantees reliable quality and competitive pricing. We are actively seeking long-term partnerships with international distributors, wholesalers, and professional trade companies to expand our reach in the global market. Contact us today for bespoke hydraulic solutions, factory wholesale inquiries, and flexible manufacturing collaborations.
