Multi Way Directional Valve 1 Spool Hydraulic Control Valve - Wholesale & OEM - Factory Direct

控制方式:气控

路数:1 联

额定流量:150 L/min (39.6 US gpm)

最大压力:230 bar (3300 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G1/4接口

品牌:BXHS

所属类别:翻斗阀

产品系列:QFCK-F20L系列翻斗阀

Packagingsize:25*20*14

Grossweight:6.50 kg

库存: 有货

描述

Multi Way Directional Valve 1 Spool Hydraulic Control Valve - Wholesale & OEM - Factory Direct

Multi Way Directional Valve 1 Spool Hydraulic Control Valve - Wholesale & OEM - Factory Direct drawing image

This multi-way directional valve with a single spool is a robust and reliable hydraulic control solution for a wide range of construction and industrial applications. It is designed for high-flow operations and features pneumatic control for precise operation.

QFCK-F20L系列翻斗阀参数
控制方式	气控
路数	1 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	整体阀
联数	1联
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)
额定流量	150 L/min (39.6 US gpm)
最大压力	210 bar (3045 psi)
进油口	G3/4接口
出油口	G1接口
接口尺寸	G3/4接口, G1接口, G1/4接口

This QFCK-F20L series multi-way directional valve is a single-spool, monoblock valve designed for heavy-duty applications in the construction, agriculture, and industrial vehicle sectors. With a rated flow of 140 L/min and a maximum pressure of 210 bar, this valve is ideal for powering telehandlers, forklifts, excavators, skid steer loaders, wheel loaders, backhoe loaders, dumpers, tractors, and harvesters. It offers pneumatic control for precise actuation and operates effectively in a wide range of ambient temperatures, making it a versatile choice for demanding environments.

Multi Way Directional Valve 1 Spool Hydraulic Control Valve - Wholesale & OEM - Factory Direct
