Multi-channel Directional Valve Pneumatic Control Valves | Manufacturer, Supplier & Distributor

控制方式:气控

路数:1 联

额定流量:50 L/min (13.2 US gpm)

最大压力:1 MPa (145 psi)

进油口:G1/4接口

出油口:G1/4接口

接口尺寸:G1/4接口

品牌:BXHS

所属类别:气动控制阀

产品系列:BKQF34系列气动控制阀

Packagingsize:15*10*8

Grossweight:0.38 kg

库存: 有货

描述

Multi-channel Directional Valve Pneumatic Control Valves | Manufacturer, Supplier & Distributor

Multi-channel Directional Valve Pneumatic Control Valves | Manufacturer, Supplier & Distributor drawing image

The BKQF34 Series multi-channel directional valve is a high-performance pneumatic control valve designed for a variety of construction and industrial applications. It offers a rated flow of 40 L/min and a maximum pressure of 1 MPa, making it ideal for use in forklifts, telehandlers, skid steer loaders, and other heavy equipment.

BKQF34系列气动控制阀参数
控制方式	气控
路数	1 联
环境温度范围	-40°C to +80°C (-40°F to +176°F)
结构类型	整体阀
联数	1联
工作粘度范围	12 - 400 mm²/s (12 cSt to 400 cSt)
额定流量	40 L/min (10.5 US gpm)
最大压力	1 MPa (145 psi)
进油口	G1/4接口
出油口	G1/4接口
接口尺寸	G1/4接口

This 1-section, monoblock valve features a single spool and is designed for use in harsh environments, with an operating temperature range of -40°C to +80°C. Its compact design and reliable performance make it a popular choice for manufacturers of construction, material handling, and agricultural equipment. The BKQF34 Series is available in a variety of configurations to meet specific application requirements. It is widely used in forklifts, telehandlers, skid steer loaders, compact wheel loaders, mini-excavators, midi-excavators, tractors, front-end loaders, harvesters, balers, and sprayers.
