P80F-G34 Hydraulic Control Valve is a monoblock valve designed for various applications. With a rated flow of 80 L/min and a max pressure of 250 bar, it offers reliable performance in demanding hydraulic systems.
| P80F系列 单块式方向阀 参数 | |
|---|---|
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制 |
| 接口尺寸 | G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 出油口 | G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹 |
| 最大压力 | 315 bar (4600 psi) |
| 额定流量 | 80 L/min (21.2 US gpm) |
| 结构类型 | 整体阀 |
| 进油口 | G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
**P80F-G34 Hydraulic Control Valve**
**Key Features:**
- Monoblock valve design for compact and efficient installation
- Rated flow of 80 L/min (21.2 US gpm) for high flow capacity
- Max pressure of 250 bar (3600 psi) for demanding applications
- Operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) for wide compatibility
- Ambient temperature range of -40°C to +80°C (-40°F to +176°F) for harsh environments
- Single spool for precise control
- Customisable and private label solutions available
**Applications:**
- Material Handling: Telehandlers, forklifts, stackers, aerial platforms
- Construction and Earth Moving: Motor graders, excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers
- Agriculture: Tractors, harvesters, sprayers
- Industrial Vehicles: Concrete boom pumps, pave rollers, rotary drilling rigs, crushers, stone cutters
The P80F-G34 Hydraulic Control Valve is an ideal choice for a wide range of hydraulic systems, providing reliable performance, customisability, and durability.
