Hydraulic Cylinder With Control Unit P120-G1 Monoblock Directional Valve | Precision Hydraulics

控制方式:手控

路数:1 联

额定流量:120 升/分钟 (31.7 美制加仑/分钟)

最大压力:250 bar (3600 psi)

进油口:G1接口

出油口:G1接口

接口尺寸:G1接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P120系列 单块式方向阀

Packagingsize:19*35*16

Grossweight:13.60 kg

库存: 有货

895 次查看了此产品

Hydraulic Cylinder With Control Unit P120-G1 Monoblock Directional Valve | Precision Hydraulics

Hydraulic Cylinder With Control Unit P120-G1 Monoblock Directional Valve | Precision Hydraulics

Hydraulic Cylinder With Control Unit P120-G1 Monoblock Directional Valve | Precision Hydraulics drawing image

The P120-G1 Monoblock Directional Valve is a compact and robust hydraulic cylinder control unit designed for use in a wide range of applications including material handling, construction, and agriculture. It features a 120 L/min flow rate, 250 bar pressure rating, and a manual control method. This unit is perfect for applications requiring precise and reliable hydraulic control.

P120系列 单块式方向阀 参数
控制方式 手控, 软轴, 一控二手柄控制, 手控+一控二
路数 1 联, 2 联, 3 联, 4 联
额定流量 120 升/分钟 (31.7 美制加仑/分钟)
最大压力 250 bar (3600 psi)
进油口 G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 3/4 NPT螺纹, 1 NPT螺纹, M36×2螺纹
出油口 G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹
接口尺寸 G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 1 NPT螺纹, M36×2螺纹
联数 1联, 2联, 3联, 4联
结构类型 整体阀
环境温度范围 -40°C to +80°C (-40°F to +176°F)
工作粘度范围 15 - 75 mm²/s (15 cSt to 75 cSt)

The P120-G1 Monoblock Directional Valve is a high-performance hydraulic cylinder control unit that offers exceptional reliability and durability. Designed for use in demanding environments, it features a robust monoblock valve construction and a 120 L/min flow rate, making it ideal for a wide range of applications. Its 250 bar pressure rating ensures it can handle heavy loads and demanding operating conditions. The manual control method provides precise and easy operation, while its compact design allows for easy integration into various systems. This unit is particularly well-suited for use in telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its wide operating temperature range (-40°C to +80°C) ensures it can perform reliably in a variety of climates.
