Our P80 Series directional valves are designed for heavy-duty applications in construction, material handling, agriculture, and industrial vehicles. These manual monoblock valves offer high flow rates and pressures, ensuring reliable operation in demanding environments. Contact us for competitive factory direct pricing on wholesale orders.
| P80系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 手控+一控二 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 80 L/min (21.2 US gpm) |
| 最大压力 | 315 bar (4600 psi) |
| 进油口 | G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
| 出油口 | G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
| 接口尺寸 | G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
The P80 Series directional valves are a robust and reliable solution for a wide range of applications. They feature a compact design, 1 section, and 1 spool, providing precise control over hydraulic fluid flow. With a rated flow of 80 L/min and a maximum pressure of 250 bar, these valves are capable of handling demanding tasks in construction, material handling, agriculture, and industrial vehicles. Our factory direct pricing and wholesale options make these valves a cost-effective solution for businesses of all sizes. We offer various customization options to meet specific requirements. Contact us today to learn more and discuss your specific needs.
